CF MOTO ZForce 950EX - Air Filter Installation

05-65
05 Engine
Loosen clamp
1
.
Put clamp
1
on air lter outlet pipe
2
.
Install air lter outlet pipe
2
.
Tighten clamp
1
.
5.3.1.3 Air Filter Installation
Put clamp
1
on breather hose
2
.
Loosen clamp
1
to install breather hose
2
.
Put clamp
1
on air lter outlet pipe.
Install air filter
4
on throttle valve and
tighten the clamp
3
.
Install T-type bushings
1
.
Install bolts
2
.
Loosen clamp
1
and put it on connecting
hose.
Install air lter inlet pipe
2
with connecting
hose on air lter.
Tighten clamp
1
.
3
4
1
2
2
1
2
1
2
1
1
1
2
052101
052102
052103
052104
