CF MOTO ZForce 950EX - Muffler Parts Inspection

CFMOTO
05-72
Remove mu󰀪er nuts
1
.
Remove graphite seal ring
2
.
Remove mu󰀪er rear pipe assy
3
.
Remove mu󰀪er joint nuts
1
.
Remove graphite seal ring
2
.
Remove mu󰀪er front pipe assy
3
.
5.3.3.2 Mu󰀪er Parts Inspection
Mu󰀪er Body Assy
Disassembly
Remove bolt
1
.
Remove mu󰀪er hanging bracket assy
2
.
Remove engine upper bracket
3
.
Remove M6 inner hex screws
1
.
1
1
2
3
1
3
1
2
1
1
3
2
052801
052802
052803
052804
