CF MOTO ZForce 950EX - Magneto Rotor; Starter Dual Gear

05-87
05 Engine
1
1
2
Remove dowel pins
1
.
Remove roller needle
2
.
5.4.18 Magneto Rotor
Use special tool: Magneto Rotor Holding
Wrench
1
to x rotor
5
.
Remove bolt
2
.
Remove spacer
3
.
Use special tool
4
to remove magneto
rotor
5
.
Remove woodru󰀨 key
1
.
Remove driven gear
2
.
5.4.19 Starter Dual Gear
Remove breather shaft
1
.
Remove middle gear
2
.
Remove breather shaft
3
.
Remove dual gear
4
.
23
5
4
1
1
2
1
3
4
2
054301
054302
054303
054304
