CF MOTO ZForce 950EX - Switches

CFMOTO
12-16
12.9 Switches
Unplug connectors between switches and
main cable. Inspect switch performance.
Stop switch
Color
Function
R Gr Y B Gr B B Br Gr B
● ●
● ● ● ● ● ●
Horn switch
Color
Function
Lg B Br G B B Br
● ●
● ● ● ● ●
R
1 Stop switch 2
Illumination
swicth
3 Dimmer switch
4 Horn switch 5
Override
switch
6
Ignition switch
lock
7
DC outlet/USB
connector
8
2WD,4WD
switch
9
Turn light
switch (EU)
10
Warning
switch (EU)
Illumination switch
Color
Function
B Br Br B Br W L B Br G B
●
●
● ●
●
● ● ●
●
●
●
●
● ●
● ● ● ● ●
Dimmer switch
Color
Function
W W L L G B B Br
● ● ● ●
● ● ● ●
R
1 2 3 4
5
6
8
9
10
7
120901
