05-77
05 Engine
Connect oxygen sensor connectors.
Install seat rear back plate assy
1
.
Install ECU, ECU service cover
2
and
diagnosis connector.
(refer to Body Covering Parts chapter).
Install driver seat
1
.
Install passenger seat
2
.
(Installation procedures refer to Seat
section.)
Install cargo box base plate assy
1
.
Install three bolts and air filter cover
2
(refer to Body Covering Parts chapter).
Install rear rack assy
1
.
Install CVT LH&RH outer deco covers
2
.
Install LH&RH rear fenders
3
.
(Installation procedures refer to Body
Covering Parts chapter.)
2
1
2
1
2
1
3
2
3
2
1
053301
053302
053303
053304
