7.2.3.1.1.- Conguration of a digital input, impulse mode.
When selecting the conguration of digital inputs in impulse mode, you can program the
following parameters:
 The input name.
 The units.
 The decimals.
 The energy meter factor.
The conguration of a digital input in impulse mode in the expansion modules is the same as
the conguration of the digital inputs in impulse mode integrated in the unit, see
“5.6.17.2.-
Conguration of digital inputs, impulse mode.”
7.2.3.1.2.- Conguration of a digital input, logic state mode.
When selecting the conguration of digital inputs in logic state mode, you can program the input
logic as positive or negative.
The conguration of a digital input in logic state mode in the expansion modules is the same as
the conguration of the digital inputs in logic state mode integrated in the unit, see “5.6.17.3.-
Conguration of digital inputs, logic state mode.”
7.2.3.2.- Relay digital outputs.
Select the output to congure on the main conguration screen of the relay digital outputs,
Figure 158.
Figure 158: Main conguration screen of relay digital outputs.
The following options appear in the lower area:
218
CVM-B100 - CVM-B150
Instruction Manual
