Comtech EF Data DMD1050TS - Page 158

DMD1050TS Satellite Modem Board
Revision 1
Web Browser 7–36 MN-DMD1050TS
Receive | Data Page
SCC Control Ratio • 1:1
• 1:2
• 1:3
• 1:4
• 1:5
• 1:6
• 1:7
This is available only when SCC is selected for the Rx
Satellite Framing.
Use to simulate the framing used by the Satellite Control
Channel option (Pass Thru Mode only). The SCC CTL
RATIO is the ratio of overhead in-band data to
synchronizing words.
EBEM Ethernet Rate
XXXXXXXXX Future option.
EBEM Embedded
Channel
• DISABLE
• ENABLE
Future option.
Enable or disable the embedded overhead channel.
EBEM Overhead
Rate
•
OFF
• 8K
• 16K
• 24K
• 32K
• 40K
• 48K
• 56K
• 64K
Future option.
Use to select the overhead channel bandwidth.
EBEM Encryption • DISABLE
• ENABLE
Future option.
Use to encrypt the transmit data. This is available when a
FIPs Module is installed on the DMD1050TS and the transit
FEC is either TPC or LDPC.
