DMD1050TS Satellite Modem Board
Revision 1
Web Browser 7–40 MN-DMD1050TS
7.7.2.6 Receive | ITA Page
Figure 7-23. Receive | ITA Page Example
Receive | ITA Page
ITA Control • DISABLED
• ENABLED
Enable or disable the ITA Control.
Margin (dBm)
•
0 to 2.00 dB
Sets link margin when operating in ITA mode.
Hysteresis (dBm)
•
0 to 2.00 dB
Sets the variation in Es/No needed to trigger a waveform
transition.
Waveform Mask
Properties
• BPSK
o 1/2
o 2/3
o 3/4
o 7/8
o 19/20
• QPSK
o 1/2
o 2/3
o 3/4
o 7/8
o 19/20
• 8-PSK
o 1/2
o 2/3
o 3/4
o 7/8
o 19/20
• 16-APSK
o 1/2
o 2/3
o 3/4
o 7/8
o 19/20
Us to select the mod/code rate.
