DMD1050TS Satellite Modem Board
Revision 1
Web Browser 7–43 MN-DMD1050TS
Interface | TX Setup Page
Eth Flow Control • DISABLED
• ENABLED
Enable or disable flow control. This is only visible when
Ethernet is selected as the interface type.
•
• ENABLED
Enable or disable the Ethernet Port Daisy Chaining or
enable it on Port 2. This is only visible when Ethernet is
selected as the interface type.
•
• PORT BASED
Use to select the priority hierarchy for processing an IEEE
803.0ac Tag, Ipv4 Type of Service Field/Differentiated
Services Field, or Ipv6 Traffic Class Field. The Port Based
priority overrides any standard priority. When operating in
this mode, Port 1 has the highest priority and Port 2 has the
lowest.
• FAIR WEIGHTED
• STRICT PRIORITY
Use to select the queue weighting of 8, 4, 2 or 1, so that
even the lowest priority traffic gets some bandwidth. Strict
Priority makes sure that the higher priority traffic transmits
before the lower priority traffic.
Strict Priority can severely limit lower priority traffic.
ETH HDLC • RADYNE
• COMTECH
• MANAGED 570
RADYNE HDLC is supported by all legacy Radyne products
that do not allow configuration of the HDLC, or Comtech
modems that use the Network Processor card in Gigabit
Bridge mode.
COMTECH HDLC is supported by the SLM5650A Modem
with Ethernet Bridge Card.
MANAGED 570 HDLC is for other Comtech HDLCs, such
as the CDM-570 and CDM-625 in standard bridge mode.
See Table 3-1.
Async Section
• ES-ES
• ESC ENHANCED
Read only; ES-ES is the normal IBS Async Channel. ESC
ENHANCED is applicable for Closed Net. It uses the
Overhead Signaling bytes in the IBS Overhead to pass
asynchronous data.
•
• RS-485
Read only; shows the ES interface type.
• 150 - 19200
Read only; shows the ES baud rate in Enhanced Async
Mode.
ES Bits/Char • 7
• 8
Read only; shows the 7- or 8-bit data.
Drop Map Section – Not available on the DMD1050TS
