DMD1050TS Satellite Modem Board
Revision 1
Web Browser 7–48 MN-DMD1050TS
Monitor | Voltages Page
Es/No (dB)
Read only, this shows the estimated Es/No as seen by the
demodulator.
RX Buffer Reset
button
Use the button to re-center the Doppler Buffer each time
the ENTER key is pressed while a Web browser page is
open.
+1.5V Tx Supply
Read only, this shows the measured voltage of the 1.5 Volt
Tx power bus inside the modem.
+1.5V Rx Supply
Read only, this shows the measured voltage of the 1.5 Volt
Rx power bus inside the modem.
+3.3V Supply
Read only, this shows the measured voltage of the +3.3
Volt power bus inside the modem.
+5V Supply
Read only, this shows the measured voltage of the +5 Volt
power bus inside the modem.
+12V Supply
Read only, this shows the measured voltage of the +12 Volt
power bus inside the modem.
+20V Supply
Read only, this shows the measured voltage of the +20 Volt
power bus inside the modem.
