Comtech EF Data DMD1050TS - Page 172

DMD1050TS Satellite Modem Board
Revision 1
Web Browser 7–50 MN-DMD1050TS
Monitor | ETH Link Status Page
JS2 Port • Down
• Unresolved
• 10 Mbps Half
• 10 Mbps Full
• 100 Mbps Half
• 100 Mbps Full
• Unused
Read only; this shows the status of the LAN Port 1.
• Down - the link is down.
• Unresolved – cannot agree on connection speed.
• 10 Mbps Half – connected at 10 Base-T Half Duplex.
• 10 Mbps Full – connected at 10 Base-T Full Duplex.
• 100 Mbps Half – connected at 100 Base-T Half
Duplex.
• 100 Mbps Full – connected at 100 Base-T Full Duplex.
• Unused – the port is not available.
JS3 Port
• Down
• Unresolved
• 10 Mbps Half
• 10 Mbps Full
• 100 Mbps Half
• 100 Mbps Full
• Unused
Read only; this shows the status of the LAN Port 2.
• Down - the link is down.
• Unresolved – cannot agree on connection speed.
• 10 Mbps Half – connected at 10 Base-T Half Duplex.
• 10 Mbps Full – connected at 10 Base-T Full Duplex.
• 100 Mbps Half – connected at 100 Base-T Half
Duplex.
• 100 Mbps Full – connected at 100 Base-T Full Duplex.
• Unused – the port is not available.
JS4 Port
•
Down
• Unresolved
• 10 Mbps Half
• 10 Mbps Full
• 100 Mbps Half
• 100 Mbps Full
• Unused
Read only; this shows the status of the FIPS Module Port.
• Down - the link is down.
• Unresolved – cannot agree on connection speed.
• 10 Mbps Half – connected at 10 Base-T Half Duplex.
• 10 Mbps Full – connected at 10 Base-T Full Duplex.
• 100 Mbps Half – connected at 100 Base-T Half
Duplex.
• 100 Mbps Full – connected at 100 Base-T Full Duplex.
• Unused – the port is not available.
WAN Status
Read only; this shows the status of the WAN Port.
