DMD1050TS Satellite Modem Board
Revision 1
Web Browser 7–58 MN-DMD1050TS
Alarms | Receive Page
Dnl Frame Lock • Current
• Latched
• Masked (checkmark)
• Unmasked (no check)
Drop/insert data is frame locked.
Dnl MFrame Lock
•
Current
• Latched
• Masked (checkmark)
• Unmasked (no check)
Drop/insert data has multiframe lock.
T1E1 Signaling
• Current
• Latched
• Masked (checkmark)
• Unmasked (no check)
The T1/E1 Signal is not locked.
IFEC Lock
•
Current
• Latched
• Masked (checkmark)
• Unmasked (no check)
This shows if the Framing Unit cannot find the expected
framing pattern.
TPC Conflict Chk
•
Current
• Latched
• Masked (checkmark)
• Unmasked (no check)
Indicates that the TPC parameters are not configured
correctly.
OFEC Lock • Current
• Latched
• Masked (checkmark)
• Unmasked (no check)
This shows if the Reed-Solomon Decoder is not locked.
Interleaver
•
Current
• Latched
• Masked (checkmark)
• Unmasked (no check)
This shows if the Reed Solomon Interleaver is not
synchronized.
RS Uncorr. Word
• Current
• Latched
• Masked (checkmark)
• Unmasked (no check)
This shows the status of the Reed Solomon uncoded word
fault.
Ebno
•
Current
• Latched
• Masked (checkmark)
• Unmasked (no check)
This shows if the Eb/No is outside of limits.
Rx Level
•
Current
• Latched
• Masked (checkmark)
• Unmasked (no check)
This shows if the Rx level is below allowable limits.
IBS BER • Current
• Latched
• Masked (checkmark)
• Unmasked (no check)
This shows if there is more than one in 1000 bits in error in
IBS Mode.
