Comtech EF Data DMD1050TS - Page 181

DMD1050TS Satellite Modem Board
Revision 1
Web Browser 7–59 MN-DMD1050TS
Alarms | Receive Page
DVB Frame Lock • Current
• Latched
• Masked (checkmark)
• Unmasked (no check)
This shows if the Rx Satellite Data Stream Framing is not
DVB.
Ebem Embedded
•
Current
• Latched
• Masked (checkmark)
• Unmasked (no check)
Indicated that the embedded channel is enabled but not in
synchronization.
Ebem Encrypt
• Current
• Latched
• Masked (checkmark)
• Unmasked (no check)
Indicated that the encryption is enabled but not in
synchronization.
Ebem Aupc Msg
•
Current
• Latched
• Masked (checkmark)
• Unmasked (no check)
Indicated that the AUPC is enabled but not receiving
incoming messages from remote.
FORCE ALARM
TEST
Use to force alarms.
RESET LATCHED
ALARMS
Use to reset (Clear) all Latched Alarms.
