DMD1050TS Satellite Modem Board
Revision 1
Web Browser 7–62 MN-DMD1050TS
7.7.4.9 Alarms | Backward Page
Figure 7-34. Alarms | Backward Page Example
IBS and IDR Backward Alarms are only available through a user interface, such as Web Browser,
SNMP, Terminal Screens and RLLP. Physical contacts are not available for the backward alarms.
Alarms | Common Page
IDR ALARMS
IDR Backwards #1
SAT Alarm
• Xmitted
• Received
SAT Control
•
Standard
• Force On
• Force Off
IDR Backwards #2
SAT Alarm
•
Xmitted
• Received
SAT Control • Standard
• Force On
• Force Off
IDR Backwards #3
SAT Alarm
• Xmitted
• Received
SAT Control
•
Standard
• Force On
• Force Off
IDR Backwards #4
SAT Alarm
•
Xmitted
• Received
SAT Control
• Standard
• Force On
• Force Off
