DMD1050TS Satellite Modem Board
Revision 1
Appendix J J–3 MN-DMD1050TS
Table J-1. Compatibility with Other DMD Modems
Modulation
Code
Rate
Data Rate Range
(kbps)
DMD20 /
DMD20 LBST
HW1 + HW6
DMD1050 /
DMD1050T /
DMD1050TS
HW3 + HW8
OM20
HW1 + HW6
Data Rate Range
(kbps)
DMD50 /
DMD2050
HW2 + HW7
DMD2050E /
DMD2050EU
HW2 + HW7 + HW24
Legacy Modes
BPSK Viterbi 1/2 2.4 – 5,000 Standard Standard Standard 2.4 – 15,000 Standard Standard
QPSK
Viterbi
1/2 4.8 – 10,000 Standard Standard Standard 4.8 – 30,000 Standard Standard
3/4 7.2 – 15,000 Standard Standard Standard 7.2 – 45,000 Standard Standard
7/8 8.4 – 17,500 Standard Standard Standard 8.4 – 52,000 Standard Standard
Viterbi + RS
1/2 4.8 – 10,000 * R / N RS Feature RS Feature RS Feature 4.8 – 30,000 * R / N RS Feature Standard
3/4 7.2 – 15,000 * R / N RS Feature RS Feature RS Feature 7.2 – 45,000 * R / N RS Feature Standard
7/8 8.4 – 17,500 * R / N RS Feature RS Feature RS Feature 8.4 – 52,000 * R / N RS Feature Standard
Sequential
1/2 4.8 – 2,048 Sequential Feature Sequential Feature Sequential Feature 4.8 – 2,048 Sequential Feature Sequential Feature
3/4 7.2 – 2,048 Sequential Feature Sequential Feature Sequential Feature 7.2 – 2,048 Sequential Feature Sequential Feature
7/8 8.4 – 2,048 Sequential Feature Sequential Feature Sequential Feature 8.4 – 2,048 Sequential Feature Sequential Feature
OQPSK
Viterbi
1/2 4.8 – 10,000 Standard Standard Standard 4.8 – 30,000 Standard Standard
3/4 7.2 – 15,000 Standard Standard Standard 7.2 – 45,000 Standard Standard
7/8 8.4 – 17,500 Standard Standard Standard 8.4 – 52,000 Standard Standard
Viterbi + RS
1/2 4.8 – 10,000 * R / N RS Feature RS Feature RS Feature 4.8 – 10,000 * R / N RS Feature Standard
3/4 7.2 – 15,000 * R / N RS Feature RS Feature RS Feature 7.2 – 15,000 * R / N RS Feature Standard
7/8 8.4 – 17,500 * R / N RS Feature RS Feature RS Feature 8.4 – 17,500 * R / N RS Feature Standard
Sequential
1/2 4.8 – 2,048 Sequential Feature Sequential Feature Sequential Feature 4.8 – 2,048 Sequential Feature Sequential Feature
3/4 7.2 – 2,048 Sequential Feature Sequential Feature Sequential Feature 7.2 – 2,048 Sequential Feature Sequential Feature
7/8 8.4 – 2,048 Sequential Feature Sequential Feature Sequential Feature 8.4 – 2,048 Sequential Feature Sequential Feature
8PSK
Trellis 2/3 9.6 – 20,000 8PSK Feature 8PSK Feature 8PSK Feature 9.6 – 52,000 8PSK Feature Standard
Trellis + RS 2/3 9.6 – 20,000 * R / N 8PSK + RS Feature 8PSK + RS Feature 8PSK + RS Feature 9.6 – 52,000 8PSK + RS Feature Standard
16QAM Viterbi
3/4 14.4 – 20,000 16QAM Feature 16QAM Feature 16QAM Feature 14.4 – 52,000 16QAM Feature Standard
7/8 16.8 – 20,000 16QAM Feature 16QAM Feature 16QAM Feature 16.8 – 52,000 16QAM Feature Standard
