Comtech EF Data DMD1050TS - Page 302

DMD1050TS Satellite Modem Board
Revision 1
Appendix J J–4 MN-DMD1050TS
Modulation
Code
Rate
Data Rate Range
(kbps)
DMD20 /
DMD20 LBST
HW1 + HW6
DMD1050 /
DMD1050T /
DMD1050TS
HW3 + HW8
OM20
HW1 + HW6
Data Rate Range
(kbps)
DMD50 /
DMD2050
HW2 + HW7
DMD2050E /
DMD2050EU
HW2 + HW7 + HW24
Viterbi + RS
3/4 14.4 – 20,000 * R / N 16QAM + RS Feature 16QAM + RS Feature 16QAM + RS Feature 14.4 – 52,000 16QAM + RS Feature Standard
7/8 16.8 – 20,000 * R / N 16QAM + RS Feature 16QAM + RS Feature 16QAM + RS Feature 16.8 – 52,000 16QAM + RS Feature Standard
DVB Modes
BPSK Viterbi
1/2 2.4 – 4,608 DVB Feature DVB Feature DVB Feature 2.4 – 4,608 DVB Feature DVB Feature
2/3 3.2 – 6,144 DVB Feature DVB Feature DVB Feature 3.2 – 6,144 DVB Feature DVB Feature
3/4 3.6 – 6,912 DVB Feature DVB Feature DVB Feature 3.6 – 6,912 DVB Feature DVB Feature
5/6 4.0 – 7,680 DVB Feature DVB Feature DVB Feature 4.0 – 7,680 DVB Feature DVB Feature
7/8 4.2 – 8,064 DVB Feature DVB Feature DVB Feature 4.2 – 8,064 DVB Feature DVB Feature
QPSK Viterbi
1/2 4.8 – 9,216 DVB Feature DVB Feature DVB Feature 4.8 – 9,216 DVB Feature DVB Feature
2/3 6.4 – 12,288 DVB Feature DVB Feature DVB Feature 6.4 – 12,288 DVB Feature DVB Feature
3/4 7.2 – 13,824 DVB Feature DVB Feature DVB Feature 7.2 – 13,824 DVB Feature DVB Feature
5/6 8.0 – 15,359 DVB Feature DVB Feature DVB Feature 8.0 – 15,359 DVB Feature DVB Feature
7/8 8.4 – 16,127 DVB Feature DVB Feature DVB Feature 8.4 – 16,127 DVB Feature DVB Feature
8PSK Trellis
2/3 9.6 – 18,431 8PSK + DVB Feature 8PSK + DVB Feature 8PSK + DVB Feature 9.6 – 18,431 8PSK + DVB Feature DVB Feature
5/6 12.0 – 20,000 8PSK + DVB Feature 8PSK + DVB Feature 8PSK + DVB Feature 12.0 – 20,000 8PSK + DVB Feature DVB Feature
8/9 12.8 – 20,000 8PSK + DVB Feature 8PSK + DVB Feature 8PSK + DVB Feature 12.8 – 20,000 8PSK + DVB Feature DVB Feature
16QAM Trellis
3/4 14.4 – 20,000 16QAM + DVB Feature 16QAM + DVB Feature 16QAM + DVB Feature 14.4 – 20,000 16QAM + DVB Feature DVB Feature
7/8 16.8 – 20,000 16QAM + DVB Feature 16QAM + DVB Feature 16QAM + DVB Feature 16.8 – 20,000 16QAM + DVB Feature DVB Feature
TPC Modes
BPSK
TPC
5/16 1.5 – 3,125 TPC Feature + HW16 TPC Feature + HW18 — 1.5 – 9,375 TPC Feature + HW16 Standard
21/44 2.3 – 4,773 TPC Feature + HW14 TPC Feature TPC Feature 2.3 – 14,318 TPC Feature + HW14 Standard
TPC (SHORT)
7/8-S 4.2 – 8,750 TPC Feature + HW15 — — 4.2 – 20,000 TPC Feature + HW15 —
QPSK TPC
21/44 4.6 – 9,545 TPC Feature + HW14 TPC Feature TPC Feature 4.6 – 20,000 TPC Feature + HW14 Standard
3/4 7.2 – 15,000 TPC Feature + HW14 TPC Feature TPC Feature 7.2 – 20,000 TPC Feature + HW14 Standard
