DMD1050TS Satellite Modem Board
Revision 1
Appendix J J–5 MN-DMD1050TS
Modulation
Code
Rate
Data Rate Range
(kbps)
DMD20 /
DMD20 LBST
HW1 + HW6
DMD1050 /
DMD1050T /
DMD1050TS
HW3 + HW8
OM20
HW1 + HW6
Data Rate Range
(kbps)
DMD50 /
DMD2050
HW2 + HW7
DMD2050E /
DMD2050EU
HW2 + HW7 + HW24
7/8 8.4 – 17,500 TPC Feature + HW14 TPC Feature TPC Feature 8.4 – 20,000 TPC Feature + HW14 Standard
0.495 64.0 – 6,132 TPC Feature + HW15 — — 64.0 – 6,132 TPC Feature + HW15 —
0.793 64.0 – 6,132 TPC Feature + HW15 — — 64.0 – 6,132 TPC Feature + HW15 —
TPC (SHORT)
7/8-S 64.0 – 17,500 TPC Feature + HW15 — — 64.0 – 20,000 TPC Feature + HW15 —
OQPSK
TPC
21/44 4.6 – 9,545 TPC Feature + HW-2 TPC Feature TPC Feature 4.6 – 20,000 TPC Feature + HW14 Standard
3/4 7.2 – 15,000 TPC Feature + HW-2 TPC Feature TPC Feature 7.2 – 20,000 TPC Feature + HW14 Standard
7/8 8.4 – 17,500 TPC Feature + HW-2 TPC Feature TPC Feature 8.4 – 20,000 TPC Feature + HW14 Standard
0.495 64.0 – 6,132 TPC Feature + HW15 — — 64.0 – 6,132 TPC Feature + HW15 —
0.793 64.0 – 6,132 TPC Feature + HW15 — — 64.0 – 6,132 TPC Feature + HW15 —
TPC (SHORT)
7/8-S 64.0 – 17,500 TPC Feature + HW15 — — 64.0 – 20,000 TPC Feature + HW15 —
8PSK TPC
3/4 10.8 – 20,000
8PSK + TPC Feature +
HW14
8PSK + TPC Feature 8PSK + TPC Feature 10.8 – 20,000
8PSK + TPC Feature +
HW14
Standard
7/8 12.6 – 20,000
8PSK + TPC Feature +
HW14
8PSK + TPC Feature 8PSK + TPC Feature 12.6 – 20,000
8PSK + TPC Feature +
HW14
Standard
0.495 64.0 – 6,132
8PSK + TPC Feature +
HW15
— — 64.0 – 6,132
8PSK + TPC Feature +
HW15
—
0.793 64.0 – 6,132
8PSK + TPC Feature +
HW15
— — 64.0 – 6,132
8PSK + TPC Feature +
HW15
—
0.750 — — — — 20,000.1 – 52,000
8PSK + TPC Feature +
HW15
—
0.875 — — — — 20,000.1 – 52,000
8PSK + TPC Feature +
HW15
—
8QAM TPC 3/4 10.8 – 20,000
8QAM + TPC Feature +
HW16
8QAM + TPC Feature +
HW18
— 10.8 – 20,000
8QAM + TPC Feature +
HW16
Standard
