DMD1050TS Satellite Modem Board
Revision 1
Appendix J J–7 MN-DMD1050TS
Modulation
Code
Rate
Data Rate Range
(kbps)
DMD20 /
DMD20 LBST
HW1 + HW6
DMD1050 /
DMD1050T /
DMD1050TS
HW3 + HW8
OM20
HW1 + HW6
Data Rate Range
(kbps)
DMD50 /
DMD2050
HW2 + HW7
DMD2050E /
DMD2050EU
HW2 + HW7 + HW24
165B Turbo Modes
1
BPSK Turbo
1/2 64 – 4,965
2
— EBEM Feature + HW17 — 64 – 14,910 EBEM Feature + HW17 Standard
2/3 64 – 6,614
2
— EBEM Feature + HW17 — 64 – 19,860 EBEM Feature + HW17 Standard
3/4 64 – 7,436
2
— EBEM Feature + HW17 — 64 – 22,329 EBEM Feature + HW17 Standard
7/8 64 – 8,673
2
— EBEM Feature + HW17 — 64 – 26,031 EBEM Feature + HW17 Standard
19/20 64 – 9,412
2
— EBEM Feature + HW17 — 64 – 28,248 EBEM Feature + HW17 Standard
QPSK Turbo
1/2 64 – 9,905
2
— EBEM Feature + HW17 — 64 – 29,730 EBEM Feature + HW17 Standard
2/3 64 – 13,180
2
— EBEM Feature + HW17 — 64 – 39,558 EBEM Feature + HW17 Standard
3/4 64 – 14,811
2
— EBEM Feature + HW17 — 64 – 44,454 EBEM Feature + HW17 Standard
7/8 64 – 17,253
2
— EBEM Feature + HW17 — 64 – 52,000 EBEM Feature + HW17 Standard
19/20 64 – 18,716
2
— EBEM Feature + HW17 — 64 – 52,000 EBEM Feature + HW17 Standard
8PSK Turbo
1/2 256 – 14,811
2
— EBEM Feature + HW17 — 256 – 44,454 EBEM Feature + HW17 Standard
2/3 256 – 19,691
2
— EBEM Feature + HW17 — 256 – 52,000 EBEM Feature + HW17 Standard
3/4 256 – 22,119
2
— EBEM Feature + HW17 — 256 – 52,000 EBEM Feature + HW17 Standard
7/8 256 – 25,746
2
— EBEM Feature + HW17 — 256 – 52,000 EBEM Feature + HW17 Standard
19/20 256 – 27,911
2
— EBEM Feature + HW17 — 256 – 52,000 EBEM Feature + HW17 Standard
16APSK Turbo
1/2 256 – 19,691
2
— EBEM Feature + HW17 — 256 – 52,000 EBEM Feature + HW17 Standard
2/3 256 – 26,150
2
— EBEM Feature + HW17 — 256 – 52,000 EBEM Feature + HW17 Standard
3/4 256 – 29,356
2
— EBEM Feature + HW17 — 256 – 52,000 EBEM Feature + HW17 Standard
7/8 256 – 34,145
2
— EBEM Feature + HW17 — 256 – 52,000 EBEM Feature + HW17 Standard
19/20 256 – 37,008
2
— EBEM Feature + HW17 — 256 – 52,000 EBEM Feature + HW17 Standard
1
The 165B Turbo Modes are calculated with the embedded channel DISABLED on a singe interface without multiplexing to provide the absolute maximum that the modem can be configured.
2
Max STANAG rates reflect the maximum user payload with the embedded channel ENABLED. This is either Ethernet or Mixed Mode with the serial MIL-STD-188-114A and is limited to 20 Mbps.
