DMD1050TS Satellite Modem Board
Revision 1
Appendix J J–8 MN-DMD1050TS
Modulation
Code
Rate
Data Rate Range
(kbps)
DMD20 /
DMD20 LBST
HW1 + HW6
DMD1050 /
DMD1050T /
DMD1050TS
HW3 + HW8
OM20
HW1 + HW6
Data Rate Range
(kbps)
DMD50 /
DMD2050
HW2 + HW7
DMD2050E /
DMD2050EU
HW2 + HW7 + HW24
LDPC Modes
BPSK
HP-LDPC 1/2 2.4 – 5,000 LDPC Feature + HW16 LDPC Feature + HW18 LDPC Feature + HW20 2.4 – 15,000 LDPC Feature + HW16 LDPC Feature
ULL-LDPC 1/2 2.4 – 4,933 LDPC Feature + HW19 — LDPC Feature + HW20 2.4 – 14,799 LDPC Feature + HW19 LDPC Feature
QPSK
HP-LDPC
1/2 4.8 – 10,000 LDPC Feature + HW16 LDPC Feature + HW18 LDPC Feature + HW20 4.8 – 20,000 LDPC Feature + HW16 LDPC Feature
2/3 6.4 – 13,333 LDPC Feature + HW16 LDPC Feature + HW18 LDPC Feature + HW20 6.4 – 20,000 LDPC Feature + HW16 LDPC Feature
3/4 7.2 – 15,000 LDPC Feature + HW16 LDPC Feature + HW18 LDPC Feature + HW20 7.2 – 20,000 LDPC Feature + HW16 LDPC Feature
ULL-LDPC
1/2 4.7 – 9,866 LDPC Feature + HW19 — LDPC Feature + HW20 4.7 – 20,000 LDPC Feature + HW19 LDPC Feature
2/3 6.3 – 13,078 LDPC Feature + HW19 — LDPC Feature + HW20 6.3 – 20,000 LDPC Feature + HW19 LDPC Feature
3/4 7.0 – 14,685 LDPC Feature + HW19 — LDPC Feature + HW20 7.0 – 20,000 LDPC Feature + HW19 LDPC Feature
OQPSK
HP-LDPC
1/2 4.8 – 10,000 LDPC Feature + HW16 LDPC Feature + HW18 LDPC Feature + HW20 4.8 – 20,000 LDPC Feature + HW16 LDPC Feature
2/3 6.4 – 13,333 LDPC Feature + HW16 LDPC Feature + HW18 LDPC Feature + HW20 6.4 – 20,000 LDPC Feature + HW16 LDPC Feature
3/4 7.2 – 15,000 LDPC Feature + HW16 LDPC Feature + HW18 LDPC Feature + HW20 7.2 – 20,000 LDPC Feature + HW16 LDPC Feature
ULL-LDPC
1/2 4.7 – 9,866 LDPC Feature + HW19 — LDPC Feature + HW20 4.7 – 20,000 LDPC Feature + HW19 LDPC Feature
2/3 6.3 – 13,078 LDPC Feature + HW19 — LDPC Feature + HW20 6.3 – 20,000 LDPC Feature + HW19 LDPC Feature
3/4 7.0 – 14,685 LDPC Feature + HW19 — LDPC Feature + HW20 7.0 – 20,000 LDPC Feature + HW19 LDPC Feature
8PSK HP-LDPC
2/3 9.6 – 20,000
8PSK + LDPC Feature +
HW16
8PSK + LDPC Feature +
HW18
8PSK + LDPC Feature +
HW20
9.6 – 20,000
8PSK + LDPC Feature +
HW20
LDPC Feature
3/4 10.8 – 20,000
8PSK + LDPC Feature +
HW16
8PSK + LDPC Feature +
HW18
8PSK + LDPC Feature +
HW20
10.8 – 20,000
8PSK + LDPC Feature +
HW16
LDPC Feature
8QAM HP-LDPC
2/3 9.6 – 20,000
8QAM + LDPC Feature
+ HW16
8QAM + LDPC Feature +
HW18
8QAM + LDPC Feature +
HW20
9.6 – 20,000
8QAM + LDPC
Feature + HW16
LDPC Feature
3/4 10.8 – 20,000
8QAM + LDPC Feature
+ HW16
8QAM + LDPC Feature +
HW18
8QAM + LDPC Feature +
HW20
10.8 – 20,000
8QAM + LDPC
Feature + HW16
LDPC Feature
16QAM HP-LDPC 3/4 14.4 – 20,000
16QAM + LDPC Feature
+ HW16
16QAM + LDPC Feature +
HW18
16QAM + LDPC Feature
+ HW20
14.4 – 20,000
16QAM + LDPC
Feature + HW16
LDPC Feature
