Comtech EF Data DMD1050TS - Page 307

DMD1050TS Satellite Modem Board
Revision 1
Appendix J J–9 MN-DMD1050TS
Modulation
Code
Rate
Data Rate Range
(kbps)
DMD20 /
DMD20 LBST
HW1 + HW6
DMD1050 /
DMD1050T /
DMD1050TS
HW3 + HW8
OM20
HW1 + HW6
Data Rate Range
(kbps)
DMD50 /
DMD2050
HW2 + HW7
DMD2050E /
DMD2050EU
HW2 + HW7 + HW24
TX Direct Sequence Spread Spectrum
BPSK
HP-LDPC-
OFF
1/2
2.4 – 5,000 LDPC Feature + HW19 — LDPC Feature + HW20 2.4 – 15,000 LDPC Feature + HW19
DSSS Feature +
LDPC Feature
FACTOR x2 2.4 – 2,500 LDPC Feature + HW19 — LDPC Feature + HW20 2.4 – 7,500 LDPC Feature + HW19
DSSS Feature +
LDPC Feature
FACTOR x4 2.4 – 1,250 LDPC Feature + HW19 — LDPC Feature + HW20 2.4 – 3,750 LDPC Feature + HW19
DSSS Feature +
LDPC Feature
FACTOR x8 2.4 – 625 LDPC Feature + HW19 — LDPC Feature + HW20 2.4 – 1,875 LDPC Feature + HW19
DSSS Feature +
LDPC Feature
FACTOR x16
2.4 – 313 LDPC Feature + HW19 — LDPC Feature + HW20 2.4 – 937 LDPC Feature + HW19
DSSS Feature +
LDPC Feature
HP-LDPC-
OFF
1/2
2.4 – 4,933 LDPC Feature + HW19 — LDPC Feature + HW20 2.4 – 4,933 LDPC Feature + HW19
DSSS Feature +
LDPC Feature
FACTOR x2 2.4 – 2,467 LDPC Feature + HW19 — LDPC Feature + HW20 2.4 – 2,466 LDPC Feature + HW19
DSSS Feature +
LDPC Feature
FACTOR x4 2.4 – 1,233 LDPC Feature + HW19 — LDPC Feature + HW20 2.4 – 1,233 LDPC Feature + HW19
DSSS Feature +
LDPC Feature
FACTOR x8 2.4 - 617 LDPC Feature + HW19 — LDPC Feature + HW20 2.4 - 616 LDPC Feature + HW19
DSSS Feature +
LDPC Feature
FACTOR x16
2.4 - 308 LDPC Feature + HW19 — LDPC Feature + HW20 2.4 - 308 LDPC Feature + HW19
DSSS Feature +
LDPC Feature
QPSK
HP-LDPC-
OFF
1/2 4.8 – 10,000 LDPC Feature + HW19 — LDPC Feature + HW20 4.8 – 10,000 LDPC Feature + HW19
DSSS Feature +
LDPC Feature
