DMD1050TS Satellite Modem Board
Revision 1
Appendix J J–10 MN-DMD1050TS
Modulation
Code
Rate
Data Rate Range
(kbps)
DMD20 /
DMD20 LBST
HW1 + HW6
DMD1050 /
DMD1050T /
DMD1050TS
HW3 + HW8
OM20
HW1 + HW6
Data Rate Range
(kbps)
DMD50 /
DMD2050
HW2 + HW7
DMD2050E /
DMD2050EU
HW2 + HW7 + HW24
FACTOR x2 4.8 – 5,000 LDPC Feature + HW19 — LDPC Feature + HW20 4.8 – 5,000 LDPC Feature + HW19
DSSS Feature +
LDPC Feature
FACTOR x4 4.8 – 2,500 LDPC Feature + HW19 — LDPC Feature + HW20 4.8 – 2,500 LDPC Feature + HW19
DSSS Feature +
LDPC Feature
FACTOR x8 4.8 – 1,250 LDPC Feature + HW19 — LDPC Feature + HW20 4.8 – 1,250 LDPC Feature + HW19
DSSS Feature +
LDPC Feature
FACTOR x16
4.8 - 625 LDPC Feature + HW19 — LDPC Feature + HW20 4.8 – 625 LDPC Feature + HW19
DSSS Feature +
LDPC Feature
HP-LDPC-
OFF
1/2
4.7 – 9,866 LDPC Feature + HW19 — LDPC Feature + HW20 4.7 – 9,866 LDPC Feature + HW19
DSSS Feature +
LDPC Feature
FACTOR x2 4.7 – 4,933 LDPC Feature + HW19 — LDPC Feature + HW20 4.7 – 4,933 LDPC Feature + HW19
DSSS Feature +
LDPC Feature
FACTOR x4 4.7 – 2,467 LDPC Feature + HW19 — LDPC Feature + HW20 4.7 – 2,466 LDPC Feature + HW19
DSSS Feature +
LDPC Feature
FACTOR x8 4.7 – 1,233 LDPC Feature + HW19 — LDPC Feature + HW20 4.7 – 1,233 LDPC Feature + HW19
DSSS Feature +
LDPC Feature
FACTOR x16
4.7 - 617 LDPC Feature + HW19 — LDPC Feature + HW20 4.7 – 616 LDPC Feature + HW19
DSSS Feature +
LDPC Feature
HP-LDPC-
OFF
2/3
6.3 – 13,078 LDPC Feature + HW19 — LDPC Feature + HW20 6.3 – 13,078 LDPC Feature + HW19
DSSS Feature +
LDPC Feature
FACTOR x2 6.3 – 6,539 LDPC Feature + HW19 — LDPC Feature + HW20 6.3 – 6,539 LDPC Feature + HW19
DSSS Feature +
LDPC Feature
FACTOR x4 6.3 – 3,270 LDPC Feature + HW19 — LDPC Feature + HW20 6.3 – 3,269 LDPC Feature + HW19
DSSS Feature +
LDPC Feature
