Comtech EF Data DMD1050TS - Page 309

DMD1050TS Satellite Modem Board
Revision 1
Appendix J J–11 MN-DMD1050TS
Modulation
Code
Rate
Data Rate Range
(kbps)
DMD20 /
DMD20 LBST
HW1 + HW6
DMD1050 /
DMD1050T /
DMD1050TS
HW3 + HW8
OM20
HW1 + HW6
Data Rate Range
(kbps)
DMD50 /
DMD2050
HW2 + HW7
DMD2050E /
DMD2050EU
HW2 + HW7 + HW24
FACTOR x8 6.3 – 1,635 LDPC Feature + HW19 — LDPC Feature + HW20 6.3 – 1,634 LDPC Feature + HW19
DSSS Feature +
LDPC Feature
FACTOR x16
6.3 0 817 LDPC Feature + HW19 — LDPC Feature + HW20 6.3 0 817 LDPC Feature + HW19
DSSS Feature +
LDPC Feature
HP-LDPC-
OFF
3/4
7.0 – 14,685 LDPC Feature + HW19 — LDPC Feature + HW20 7.0 – 14,686 LDPC Feature + HW19
DSSS Feature +
LDPC Feature
FACTOR x2 7.0 – 7,342 LDPC Feature + HW19 — LDPC Feature + HW20 7.0 – 7,342 LDPC Feature + HW19
DSSS Feature +
LDPC Feature
FACTOR x4 7.0 – 3,671 LDPC Feature + HW19 — LDPC Feature + HW20 7.0 – 3,671 LDPC Feature + HW19
DSSS Feature +
LDPC Feature
FACTOR x8 7.0 – 1,836 LDPC Feature + HW19 — LDPC Feature + HW20 7.0 – 1,835 LDPC Feature + HW19
DSSS Feature +
LDPC Feature
FACTOR x16
7.0 - 918 LDPC Feature + HW19 — LDPC Feature + HW20 7.0 - 917 LDPC Feature + HW19
DSSS Feature +
LDPC Feature
OQPSK
HP-LDPC-
OFF
1/2
4.8 – 10,000 LDPC Feature + HW19 — LDPC Feature + HW20 4.8 – 10,000 LDPC Feature + HW19
DSSS Feature +
LDPC Feature
FACTOR x2 4.8 – 5,000 LDPC Feature + HW19 — LDPC Feature + HW20 4.8 – 5,000 LDPC Feature + HW19
DSSS Feature +
LDPC Feature
FACTOR x4 4.8 – 2,500 LDPC Feature + HW19 — LDPC Feature + HW20 4.8 – 2,500 LDPC Feature + HW19
DSSS Feature +
LDPC Feature
FACTOR x8 4.8 – 1,250 LDPC Feature + HW19 — LDPC Feature + HW20 4.8 – 1,250 LDPC Feature + HW19
DSSS Feature +
LDPC Feature
FACTOR x16
4.8 – 625 LDPC Feature + HW19 — LDPC Feature + HW20 4.8 – 625 LDPC Feature + HW19
DSSS Feature +
LDPC Feature
