DMD1050TS Satellite Modem Board
Revision 1
Appendix J J–14 MN-DMD1050TS
Modulation
Code
Rate
Data Rate Range
(kbps)
DMD20 /
DMD20 LBST
HW1 + HW6
DMD1050 /
DMD1050T /
DMD1050TS
HW3 + HW8
OM20
HW1 + HW6
Data Rate Range
(kbps)
DMD50 /
DMD2050
HW2 + HW7
DMD2050E /
DMD2050EU
HW2 + HW7 + HW24
TRANSEC (HW28) Counter Mode (Interoperable with MD-1366)
3
BPSK Turbo
1/2 64 – 4,965
4
— EBEM Feature + HW28 — 64 – 14,901 EBEM Feature + HW28 Standard
2/3 64 – 6,614
4
— EBEM Feature + HW28 — 64 – 19,848 EBEM Feature + HW28 Standard
3/4 64 – 7,436
4
— EBEM Feature + HW28 — 64 – 22,320 EBEM Feature + HW28 Standard
7/8 64 – 8,673
4
— EBEM Feature + HW28 — 64 – 26,019 EBEM Feature + HW28 Standard
19/20 64 – 9,412
4
— EBEM Feature + HW28 — 64 – 28,236 EBEM Feature + HW28 Standard
QPSK Turbo
1/2 64 – 9,905
4
— EBEM Feature + HW28 — 64 – 29,715 EBEM Feature + HW28 Standard
2/3 64 – 13,180
4
— EBEM Feature + HW28 — 64 – 39,540 EBEM Feature + HW28 Standard
3/4 64 – 14,811
4
— EBEM Feature + HW28 — 64 – 44,433 EBEM Feature + HW28 Standard
7/8 64 – 17,253
4
— EBEM Feature + HW28 — 64 – 51,756 EBEM Feature + HW28 Standard
19/20 64 – 18,716
4
— EBEM Feature + HW28 — 64 – 52,000 EBEM Feature + HW28 Standard
8PSK Turbo
1/2 256 – 14,811
4
— EBEM Feature + HW28 — 256 – 44,433 EBEM Feature + HW28 Standard
2/3 256 – 19,691
4
— EBEM Feature + HW28 — 256 – 52,000 EBEM Feature + HW28 Standard
3/4 256 – 22,119
4
— EBEM Feature + HW28 — 256 – 52,000 EBEM Feature + HW28 Standard
7/8 256 – 25,746
4
— EBEM Feature + HW28 — 256 – 52,000 EBEM Feature + HW28 Standard
19/20 256 – 27,911
4
— EBEM Feature + HW28 — 256 – 52,000 EBEM Feature + HW28 Standard
16APSK Turbo
1/2 256 – 19,691
4
— EBEM Feature + HW28 — 256 – 52,000 EBEM Feature + HW28 Standard
2/3 256 – 26,150
4
— EBEM Feature + HW28 — 256 – 52,000 EBEM Feature + HW28 Standard
3/4 256 – 29,356
4
— EBEM Feature + HW28 — 256 – 52,000 EBEM Feature + HW28 Standard
7/8 256 – 34,145
4
— EBEM Feature + HW28 — 256 – 52,000 EBEM Feature + HW28 Standard
19/20 256 – 37,008
4
— EBEM Feature + HW28 — 256 – 52,000 EBEM Feature + HW28 Standard
3
When running TRANSEC, the 165B Turbo Modes require the embedded channel to be ENABLED and calculated on a single interface without multiplexing to provide the absolute maximum that the modem can be configured.
The TRANSEC itself does not expand the user data, only the application of the embedded channel.
4
Max STANAG rates reflect the maximum user payload with the embedded channel ENABLED. This is either Ethernet or Mixed Mode with the serial MIL-STD-188-114A and is limited to 20 Mbps.
