DMD1050TS Satellite Modem Board
Revision 1
Appendix J J–15 MN-DMD1050TS
Modulation
Code
Rate
Data Rate Range
(kbps)
DMD20 /
DMD20 LBST
HW1 + HW6
DMD1050 /
DMD1050T /
DMD1050TS
HW3 + HW8
OM20
HW1 + HW6
Data Rate Range
(kbps)
DMD50 /
DMD2050
HW2 + HW7
DMD2050E /
DMD2050EU
HW2 + HW7 + HW24
TRANSEC (HW28) Block Mode (Interoperable with SLM-5650A) HW-27 Frame Expansion: (3 + 16 * N) / (16 * N), N = 1…16
BPSK TPC
5/16 1.5 – 2,632 TPC Feature + HW27 TPC Feature + HW27 — 1.5 – 7,895 TPC Feature + HW27 Standard
21/44 2.3 – 4,019 TPC Feature + HW27 TPC Feature + HW27 TPC Feature + HW27 2.3 – 12,057 TPC Feature + HW27 Standard
QPSK TPC
21/44 4.6 – 8,038 TPC Feature + HW27 TPC Feature + HW27 TPC Feature + HW27 4.6 – 20,000 TPC Feature + HW27 Standard
3/4 7.2 – 12,632 TPC Feature + HW27 TPC Feature + HW27 TPC Feature + HW27 7.2 – 20,000 TPC Feature + HW27 Standard
7/8 8.4 – 14,737 TPC Feature + HW27 TPC Feature + HW27 TPC Feature + HW27 8.4 – 20,000 TPC Feature + HW27 Standard
OQPSK TPC
21/44 4.6 – 8,038 TPC Feature + HW27 TPC Feature + HW27 TPC Feature + HW27 4.6 – 20,000 TPC Feature + HW27 Standard
3/4 7.2 – 12,632 TPC Feature + HW27 TPC Feature + HW27 TPC Feature + HW27 7.2 – 20,000 TPC Feature + HW27 Standard
7/8 8.4 – 14,737 TPC Feature + HW27 TPC Feature + HW27 TPC Feature + HW27 8.4 – 20,000 TPC Feature + HW27 Standard
8PSK TPC
3/4 10.8 – 18,947
8PSK + TPC Feature +
HW27
8PSK + TPC Feature +
HW27
8PSK + TPC Feature +
HW27
10.8 – 20,000
8PSK + TPC Feature +
HW27
Standard
7/8 12.6 – 20,000
8PSK + TPC Feature +
HW27
8PSK + TPC Feature +
HW27
8PSK + TPC Feature +
HW27
12.6 – 20,000
8PSK + TPC Feature +
HW27
Standard
8QAM TPC
3/4 10.8 – 18,974
8PSK + TPC Feature +
HW27
8PSK + TPC Feature +
HW27
8PSK + TPC Feature +
HW27
10.8 – 20,000
8PSK + TPC Feature +
HW27
Standard
7/8 12.6 – 20,000
8PSK + TPC Feature +
HW27
8PSK + TPC Feature +
HW27
8PSK + TPC Feature +
HW27
12.6 – 20,000
8PSK + TPC Feature +
HW27
Standard
16QAM TPC
3/4 14.4 – 20,000
16QAM + TPC Feature
+ HW27
16QAM + TPC Feature +
HW27
16QAM + TPC Feature +
HW27
14.4 – 20,000
16QAM + TPC Feature +
HW27
Standard
7/8 16.8 – 20,000
16QAM + TPC Feature
+ HW27
16QAM + TPC Feature +
HW27
16QAM + TPC Feature +
HW27
16.8 – 20,000
16QAM + TPC Feature +
HW27
Standard
BPSK
HP-LDPC 1/2 2.4 – 4,211 LDPC Feature + HW27 LDPC Feature + HW27 LDPC Feature + HW27 2.4 – 12,632 LDPC Feature + HW27 LDPC Feature
ULL-LDPC 1/2 2.4 – 4,154 LDPC Feature + HW27 — LDPC Feature + HW27 2.4 – 12,463 LDPC Feature + HW27 LDPC Feature
QPSK HP-LDPC 1/2 4.8 – 8,421 LDPC Feature + HW27 LDPC Feature + HW27 LDPC Feature + HW27 4.8 – 20,000 LDPC Feature + HW27 LDPC Feature
