DMD1050TS Satellite Modem Board
Revision 1
Appendix J J–16 MN-DMD1050TS
Modulation
Code
Rate
Data Rate Range
(kbps)
DMD20 /
DMD20 LBST
HW1 + HW6
DMD1050 /
DMD1050T /
DMD1050TS
HW3 + HW8
OM20
HW1 + HW6
Data Rate Range
(kbps)
DMD50 /
DMD2050
HW2 + HW7
DMD2050E /
DMD2050EU
HW2 + HW7 + HW24
2/3 6.4 – 11,228 LDPC Feature + HW27 LDPC Feature + HW27 LDPC Feature + HW27 6.4 – 20,000 LDPC Feature + HW27 LDPC Feature
3/4 7.2 – 12,632 LDPC Feature + HW27 LDPC Feature + HW27 LDPC Feature + HW27 7.2 – 20,000 LDPC Feature + HW27 LDPC Feature
ULL-LDPC
1/2 4.7 – 8,308 LDPC Feature + HW27 — LDPC Feature + HW27 4.7 – 20,000 LDPC Feature + HW27 LDPC Feature
2/3 6.3 – 11,013 LDPC Feature + HW27 — LDPC Feature + HW27 6.3 – 20,000 LDPC Feature + HW27 LDPC Feature
3/4 7.0 – 12,366 LDPC Feature + HW27 — LDPC Feature + HW27 7.0 – 20,000 LDPC Feature + HW27 LDPC Feature
OQPSK
HP-LDPC
1/2 4.8 – 8,421 LDPC Feature + HW27 LDPC Feature + HW27 LDPC Feature + HW27 4.8 – 20,000 LDPC Feature + HW27 LDPC Feature
2/3 6.4 – 11,228 LDPC Feature + HW27 LDPC Feature + HW27 LDPC Feature + HW27 6.4 – 20,000 LDPC Feature + HW27 LDPC Feature
3/4 7.2 – 12,632 LDPC Feature + HW27 LDPC Feature + HW27 LDPC Feature + HW27 7.2 – 20,000 LDPC Feature + HW27 LDPC Feature
ULL-LDPC
1/2 4.7 – 8,308 LDPC Feature + HW27 — LDPC Feature + HW27 4.7 – 20,000 LDPC Feature + HW27 LDPC Feature
2/3 6.3 – 11,013 LDPC Feature + HW27 — LDPC Feature + HW27 6.3 – 20,000 LDPC Feature + HW27 LDPC Feature
3/4 7.0 – 12,366 LDPC Feature + HW27 — LDPC Feature + HW27 7.0 – 20,000 LDPC Feature + HW27 LDPC Feature
8PSK HP-LDPC
2/3 9.6 – 16,842
8PSK + LDPC Feature +
HW27
8PSK + LDPC Feature +
HW27
8PSK + LDPC Feature +
HW27
9.6 – 20,000
8PSK + LDPC Feature +
HW27
LDPC Feature
3/4 10.8 – 18,947
8PSK + LDPC Feature +
HW27
8PSK + LDPC Feature +
HW27
8PSK + LDPC Feature +
HW27
10.8 – 20,000
8PSK + LDPC Feature +
HW27
LDPC Feature
8QAM HP-LDPC
2/3 9.6 – 16,842
8QAM + LDPC Feature
+ HW27
8QAM + LDPC Feature +
HW27
8QAM + LDPC Feature +
HW27
9.6 – 20,000
8QAM + LDPC Feature +
HW27
LDPC Feature
3/4 10.8 – 18,947
8QAM + LDPC Feature
+ HW27
8QAM + LDPC Feature +
HW27
8QAM + LDPC Feature +
HW27
10.8 – 20,000
8QAM + LDPC Feature +
HW27
LDPC Feature
16QAM HP-LDPC 3/4 14.4 – 20,000
16QAM + LDPC Feature
+ HW27
16QAM + LDPC Feature +
HW27
16QAM + LDPC Feature
+ HW27
14.4 – 20,000
16QAM + LDPC Feature
+ HW27
LDPC Feature
