xStack® DGS-3620 Series Layer 3 Managed Stackable Gigabit Switch CLI Reference Guide
1152
true - Specifies full-duplex mode.
false - Specifies half-duplex mode.
auto - The switch will automatically determine the P2P mode.
state - Decide if this port supports the STP functionality.
enable - Enable to support STP functionality.
disable - Disable STP functionality support.
restricted_role - Decide if this port is to be selected as Root Port or not. The default value is
false.
true - Decide that this port is not to be selected as Root Port.
false - Decide that this port is to be selected as Root Port.
restricted_tcn - Decide if this port is to propagate a topology change or not. The default value is
false.
true - Specifies not to propagate a topology change.
false - Specifies to propagate a topology change.
fbpdu - Decide if this port will flood STP BPDU when STP functionality is disabled.
enable - Enable port to flood STP BPDU when STP functionality is disabled.
disable - Disable port from flooding STP BPDU when STP functionality is disabled.
Restrictions
Only Administrators, Operators and Power-Users can issue this command.
Example
To configure STP ports:
DGS-3620-28PC:admin# config stp ports 1 externalCost auto
Command: config stp ports 1 externalCost auto
Success.
103-15 config stp mst_ports
Description
Internal Path Cost and Port Priority of a Port in MSTI can be separately configured to different
values from the configuration of CIST (instance ID = 0).
Format
config stp mst_ports <portlist> instance_id <value 0-64> {internalCost [auto | <value 1-
200000000>] | priority <value 0-240>}(1)
Parameters
<portlist> - Enter a range of ports.
instance_id - Specifies an instance ID.
<value 0-64> - Instance = 0 represents CIST, Instance from 1 to 64 represents MSTI 1 to
internalCost - The Port Path Cost used in MSTP.
auto - Specifies to automatically determine the internal cost.
<value 1-200000000> - Enter a value between 1 and 200000000.
priority - Specifies the Port Priority.
