xStack® DGS-3620 Series Layer 3 Managed Stackable Gigabit Switch CLI Reference Guide
118
Parameters
<value 1-5> - Enter the index of the CPU access list profile.
add access_id - Specifies the index of an access list entry to add. The range of this value is 1 to
100.
auto_assign - Specifies to automatically assign the access ID.
<value 1-100> - Enter an access ID between 1 and 100.
ethernet - Specifies an Ethernet CPU access control list rule.
vlan - Specifies the VLAN name.
<vlan_name 32> -Specifies the VLAN name. The maximum length is 32 characters.
vlanid - Specifies the VLAN ID.
<vlanid 1-4094> - Enter the VLAN ID between 1 and 4094.
source_mac - Specifies the source MAC address.
<macaddr> - Enter the source MAC address.
destination_mac - Specifies the destination MAC address.
<macaddr> - Enter the destination MAC address.
802.1p - Specifies the value of the 802.1p priority tag.
<value 0-7> - Enter the value of the 802.1p priority tag. The priority tag ranges from 1 to 7.
ethernet_type - Specifies the Ethernet type.
<hex 0x0-0xffff> - Enter the Ethernet type.
ip - Specifies an IP access control list rule.
vlan - Specifies the VLAN name.
<vlan_name 32> -Specifies the VLAN name. The maximum length is 32 characters.
vlanid - Specifies the VLAN ID.
<vlanid 1-4094> - Enter the VLAN ID between 1 and 4094.
source_ip - Specifies an IP source address.
<ipaddr> - Enter an IP source address.
destination_ip - Specifies an IP destination address.
<ipaddr> - Enter an IP destination address.
dscp - Specifies the value of DSCP.
<value 0-63> - Enter the value of DSCP. The DSCP value ranges from 0 to 63.
icmp - Specifies the ICMP.
type - (Optional) Specifies that the rule will apply to the ICMP Type traffic value.
<value 0-255> - Enter the value between 0 and 255.
code - (Optional) Specifies that the rule will apply to the ICMP Code traffic value.
<value 0-255> - Enter the value between 0 and 255.
igmp - Specifies the IGMP.
type - (Optional) Specifies that the rule will apply to the IGMP Type traffic value.
<value 0-255> - Enter the value between 0 and 255.
tcp - Specifies TCP.
src_port - (Optional) Specifies that the rule will apply to a range of TCP source ports.
<value 0-65535> - Enter the value between 0 and 65535.
dst_port - (Optional) Specifies that the rule will apply to a range of TCP destination ports.
<value 0-65535> - Enter the value between 0 and 65535.
flag - Specifies the TCP flag field value.
all – Specifies to check all paramenters below.
urg - (Optional) Specifies Urgent Pointer field significant.
ack - (Optional) Specifies Acknowledgment field significant.
psh - (Optional) Specifies Push Function.
rst - (Optional) Specifies to reset the connection.
syn - (Optional) Specifies to synchronize sequence numbers.
fin - (Optional) No more data from sender.
udp - Specifies UDP.
src_port - (Optional) Specifies the UDP source port range.
<value 0-65535> - Enter the value between 0 and 65535.
dst_port - (Optional) Specifies the UDP destination port range.
<value 0-65535> - Enter the value between 0 and 65535.
protocol_id - Specifies that the rule will apply to the value of IP protocol ID traffic.
<value 0-255> - Enter the value between 0 and 255.
user_define - (Optional) Specifies that the rule will apply to the IP protocol ID and that the
