xStack® DGS-3620 Series Layer 3 Managed Stackable Gigabit Switch CLI Reference Guide

1284

Example

To display the PVID auto-assignment state:

DGS-3620-28PC:admin#show pvid auto_assign

PVID Auto-assignment: Enabled.

DGS-3620-28PC:admin#
