xStack® DGS-3620 Series Layer 3 Managed Stackable Gigabit Switch CLI Reference Guide
126
drop - Enter this parameter to drop packets that are in the yellow flow.
counter - (Optional) Use this parameter to enable or disable the packet counter for the
specified ACL entry in the green flow.
enable - Enable the packet counter for the specified ACL entry in the green flow.
disable - Disable the packet counter for the specified ACL entry in the green flow.
violate - This field denotes the red packet flow. Red packet flows may have excess packets
permitted through or dropped. Users may replace the DSCP field of these packets by
checking its radio button and entering a new DSCP value in the allotted field.
permit - Enter this parameter to allow packet flows that are in the red flow.
replace_dscp - Specifies to change the DSCP of the packet.
<value 0-63> - Enter the replacement DSCP of the packet here. This value must be
between 0 and 63.
drop - Enter this parameter to drop packets that are in the red flow.
counter - (Optional) Use this parameter to enable or disable the packet counter for the
specified ACL entry in the green flow.
enable - Enable the packet counter for the specified ACL entry in the green flow.
disable - Disable the packet counter for the specified ACL entry in the green flow.
delete - Use this parameter to delete the specified flow meter.
Restrictions
Only Administrators, Operators and Power-Users can issue this command.
Example
To configure a two rate, three color flow meter:
DGS-3620-28PC:admin#config flow_meter profile_id 1 access_id 1 tr_tcm cir 1000
cbs 200 pir 2000 pbs 200 conform replace_dscp 21 exceed drop violate permit
Command: config flow_meter profile_id 1 access_id 1 tr_tcm cir 1000 cbs 200 pir
2000 pbs 200 conform replace_dscp 21 exceed drop violate permit
Success.
DGS-3620-28PC:admin#
To replace DSCP action changed to perform on conform (green) and unconform (yellow and red)
packets:
DGS-3620-28PC:admin# config flow_meter profile_id 1 access_id 1 tr_tcm cir 1000
cbs 200 pir 2000 pbs 200 exceed permit replace_dscp 21 violate permit
replace_dscp 21
Command: config flow_meter profile_id 1 access_id 1 tr_tcm cir 1000 cbs 200 pir
2000 pbs 200 exceed permit replace_dscp 21 violate permit replace_dscp 21
Success.
DGS-3620-28PC:admin#
5-15 show flow_meter
Description
This command is used to display the flow meter table.
