xStack® DGS-3620 Series Layer 3 Managed Stackable Gigabit Switch CLI Reference Guide
259
Example
To configure the LCK function state as enabled and specify a client level of 5:
DGS-3620-28PC:admin# config cfm lock md op-domain ma op-ma mepid 1 state enable
level 5
Command: config cfm lock md op-domain ma op-ma mepid 1 state enable level 5
Success.
DGS-3620-28PC:admin#
15-30 config cfm trap
Description
This command is used to configure the state of the CFM trap.
Format
config cfm trap [ais | lock] state [enable | disable]
Parameters
ais - Specifies the AIS trap status to be configured. If the trap status of AIS is enabled, a trap will
be sent out when an ETH-AIS event occurs or clears.
lock - Specifies the LCK trap status that to be configured. If the trap status of LCK is enabled, a
trap will be sent out wnen an ETH-LCK event occurs or clears.
stateSpecifies the state of the CFM trap.
enableEnable the CFM trap state. This is the default.
disableDisable the CFM trap state.
Restrictions
Only Administrators, Operators and Power-Users can issue this command. (EI Mode Only
Command)
Example
DGS-3620-28PC:admin#config cfm trap ais state enable
Command: config cfm trap ais state enable
Success.
DGS-3620-28PC:admin#
15-31 cfm dm
Description
This command is used to start a frame delay measurement test on an MEP. It will result in the
MEP periodically sending a DMM message to a remote MEP in the diagnostic interval. The system
will calculate the Frame Delay (FD) and Frame Delay Variation (FDV) based on the received DMR
