xStack® DGS-3620 Series Layer 3 Managed Stackable Gigabit Switch CLI Reference Guide
320
Options: 0x2
.... ...0 = 0 Bit Isn't Set
.... ..1. = E: ExternalRoutingCapability
.... .0.. = MC: NOT Multicast Capable
.... 0... = N/P: NSSA Bit
...0 .... = EA: Not Support Rcv And Fwd EA_LSA
..0. .... = DC: Not Support Handling Of Demand Circuits
.0.. .... = O: O Bit Isn't Set
0... .... = 7 Bit Isn't Set
LS Sequence Number: 0x80000002
Length: 36
Netmask: 0.0.0.0
Metric: 0
Forwarding Address: 0.0.0.0
External Route Tag: 0
Internal Field:
Del_flag: 0x0 I_ref_count: 0 Seq: 0x80000002 Csum: 0x77be
Rxtime: 2301 Txtime: 0 Orgage: 0
Current Time: 3156
DGS-3620-28PC:admin#
20-24 debug ospf show flag
Description
This command is used to display the OSPF debug flag setting.
Format
debug ospf show flag
Parameters
None.
Restrictions
Only Administrator level users can issue this command.
Example
To show the current OSPF debug flag setting:
DGS-3620-28PC:admin# debug ospf show flag
Command: debug ospf show flag
Global State: Enabled
Current OSPF Flags Setting:
Neighbor State Change
