xStack® DGS-3620 Series Layer 3 Managed Stackable Gigabit Switch CLI Reference Guide

511

DGS-3620-28PC:admin# change drive unit 3 c:

Command: change drive unit 3 c:

Current work directory: "/unit3:/c:".

DGS-3620-28PC:admin#
