xStack® DGS-3620 Series Layer 3 Managed Stackable Gigabit Switch CLI Reference Guide

782

Example

To display mirroring configuration:

DGS-3620-28PC:admin#show mirror

Command: show mirror

Mirror Global State: Enabled

Group ID : 1

State : Enabled

Target Port : 1:1

Source Ports

RX : 1:2-1:3

TX : 1:2-1:3

Source VLANs

RX : 2-3

DGS-3620-28PC:admin#
