xStack® DGS-3620 Series Layer 3 Managed Stackable Gigabit Switch CLI Reference Guide

787

Source : FF80::200

Group : FF1E::0202

Downstream VLAN : 2

Member Ports : 2,5,8

Status : Inactive

Total Entries: 2

DGS-3620-28PC:admin#
