xStack® DGS-3620 Series Layer 3 Managed Stackable Gigabit Switch CLI Reference Guide

935

Command: show ospfv3 virtual_link 1.1.1.1 60.60.60.60

Transit Area ID: 1.1.1.1 Virtual Neighbor Router ID: 60.60.60.60

Hello Interval: 10 Dead Interval: 60

Transmit Delay: 1 Retransmit Time: 5

Instance ID: 0

Virtual Link Status: Down

Total Entries: 1

DGS-3620-28PC:admin#
