Built-In Calibration for Top-Mount
Reference Manual
205
4.
With the sc
anner powered on and the
conveyor st
opped,
tape a piece of
paper on the conveyor
directly below the top-mounted sca
nner.
5.
Suspend a plumb bob from the 0 (zero) locato
r on the face of the scanner to
the paper placed on
the conveyor.
The scanner must be mounted with it
s face parallel and level with the conveyor sur-
face.
216
218
