Datalogic Heron HD3100 User Manual

Introduction
2 Heron™ HD3130
Figure 1. Correct positioning of scanner
AB
About this Manual
This Product Reference Guide (PRG) is provided for users seeking advanced
technical information, including connection, programming, maintenance and
specifications. The Quick Reference Guide (QRG) and other publications associ-
ated with this product are downloadable free of charge from the website listed
on
t
he back cover of this manual.
Typically, units are factory-programmed for the most common terminal and
c
o
mmunications settings. If you need to modify any programmable settings,
custom configuration can be accomplished by scanning the programming bar
codes within this guide.
Programming can alternatively be performed using the
Datalogic Aladdin™
Configuration application, which is available from the Datalogic website listed
on the back cover of this manual. This multi-platform utility program allows
device configuration using a PC. It communicates to the device using a serial or
USB cable and can also create configuration bar codes to print.
Overview
Chapter 1, Introduction provides a product overview, unpacking instructions, and
cable connection information.
Chapter 2, Setup presents information about unpacking and setting up the scan-
ner, and interface configuration bar codes and details.
Chapter 3, Configuration Using Bar Codes provides instructions and bar code labels
for customizing your scanner. There are diff
erent sections for interface types,
general features, data formatting, and symbology-specific features.
Chapter 4, References provides details concerning programmable features.
Appendix A, Technical Specifications lists physical and performance characteristics,
as well as environmental and regulatory specific
ations. It also provides stan-
dard cable pin-outs and descripti
ons of the functions and behaviors of the
scanner’s LED and Speaker indicators.
Appendix B, Standard Defaults references common factory default settings for
scanner features and options.
Appendix C, Sample Bar Codes offers sample bar codes of several common sym-
bologies.
Appendix D, Keypad includes numeric bar codes to be scanned for certain
parameter settings.
Appendix E, Scancode Tables lists control character emulation information for
Wedge and USB Keyboard interfaces.

Datalogic Heron HD3100 Specifications

General

Brand	Datalogic
Model	Heron HD3100
Category	Barcode Reader
Language	English
