RS-232 ONLY Interface Enter/Exit Programming Mode
Product Reference Guide 21
RS-232 ONLY Interface
Use the programming bar codes in this chapter if modifications to the standard
RS-232 interface settings are necessary to meet your system’s requirements.
Additional settings which apply to both the RS-232 and USB interfaces are
available in
Chapter 5, RS-232/USB-COM Interfaces.
BAUD RATE on page 21 PARITY on page 23
STOP BITS on page 22 HANDSHAKING CONTROL on page 24
RS-232 Standard Factory Settings
Reference Appendix B, Standard Defaults for a listing of standard factory set-
tings.
Baud Rate
Baud rate is the number of bits of data transmitted per second. Set the scan-
ner's baud rate to match the baud rate sett
ing of the host device. With an
improper baud rate setting, data may not reach the host correctly.
Baud Rate = 1200
Baud Rate = 2400
Baud Rate = 4800
Baud Rate = 9600
DEFAULT
$CR2BA00
$CR2BA01
$CR2BA02
$CR2BA03
