Product Reference Guide
249
Appendix A
Technical Specifications
The table below contains Physical and Performance Characteristics, User Envi-
ronment and Regulatory information.
Table 25 provides Standard Cable Pinouts.
Table 23. Technical Specifications
Item Description
Electrical Features
Power Supply
RS-232 interface
5 Vdc
±
5%
Consumption:
Max operating current @ 5V: <500 mA
Typical operating (changing colors) current @ 5V < 300
mA
Max. Scan Rate 270 scans/sec
Reading Indicators Side and Top Illumination, Good Re
ad Spot, Beep or Jingle
Optical Features
Sensor CCD solid state (2500 pixels)
Illuminator LED array
Wavelength 617 nm
LED Safety Class Exempt according to IEC 62471
DOF (Depth of Field)
Typical
5 mils
: 5 to 15.0 cm / 2.0 to 6.0 in (CODE 39, PCS 90%)
10 mils: 2 to 35.0 cm / 0,8 to 13.8 in (CODE 39, PCS 90%)
13 mils: 2 to 40.0 cm / 0,8 to 15.7 in (EAN13, PCS 90%) 20
mils: 2 to 60.0 cm / 0,8 to 23.6 in (CODE 39, PCS 90%)
Max. Resolution 0.10 mm (4 mils)
PCS (Datalogic Test Chart) minimum 15%
