References
238 Heron™ HD3130
RGB LED Features
RGB Good Read Raising/Falling Time
This parameter specifies the time it will take for the RGB good read to change
the status from an Off state to Brightness state, or back.
The delay can be set within a range of zero (0) to 5000 milliseconds (5 seconds)
i
n
100ms increments. A setting of zero specifies no delay.
To set the time:
1. Determine the desired setting in milliseconds.
2. Divide the desired setting by 100 (setting is in 100ms increments). Pad the
re
sult with leading zeroes to yield two digits. For example: 0 = 00, 5 = 05,
20 = 20, etc.
3. Scan the ENTER/EXIT PROGRAMMING MODE bar code to enter Program-
ming Mode.
4. Scan the bar code: SELECT RGB
GOOD READ
RAISING TIME on
page 77
or
RBG GOOD READ FALLING TIME on
page 78
.
5. Scan the appropriate two digits from the keypad in
Appendix D, Keypad
, that
represent the duration which was determined in the steps above.
NOTE
If you make a mistake before the last character, scan the CANCEL bar code
to abor
t and not save the entry string. You can then start again at the
beginning.
6. Scan the ENTER/EXIT PROGRAMMING MODE bar code to exit.
This completes the procedure. See the following table for examples of how to
set this feature.
Table 15. RGB Good Read Raising/Falling Time Examples
STEP ACTION EXAMPLES
1 Desired Setting
100ms 200ms 1000ms (1 sec.) 5000ms (5 secs.)
2 Divide by 100
01 02 10 50
3 Scan ENTER/EXIT PROGRAMMING MODE
4 Scan SELECT RGB GOOD READ RAISING/FALLING TIME
5
Scan Two Characters From
Appendix D, Keypad
‘0’ and ‘1’ ‘0’ and ‘2’ ‘1’ and ‘0’ ‘5’ and ‘0’
6 Scan ENTER/EXIT PROGRAMMING MODE
