USB Keyboard Speed

Product Reference Guide

USB Keyboard Speed

This option specifies the USB poll rate for a USB Keyboard.

NOTE

DEFAULT

USB Keyboard Speed = 1ms

USB Keyboard Speed = 2ms

USB Keyboard Speed = 3ms

USB Keyboard Speed = 5ms

USB Keyboard Speed = 7ms

USB Keyboard Speed = 10ms

This feature applies ONLY to the USB Keyboard interface.

$CKBSP01

$CKBSP02

$CKBSP03

$CKBSP05

$CKBSP07

$CKBSP0A
