Enter/Exit Programming Mode Code 5

208 Heron™ HD3130

Code 5 Check Character Transmission

This feature enables/disables transmission of an optional Code 5 check charac-

ter.

Code 5 Check Character Transmission = Don’t Send

Code 5 Check Character Transmission = Send

DEFAULT

Code 5 Hex to Decimal Conversion

This feature enables/disables the conversion of hexadecimal label data to dec-

imal label data.

Code 5 Hex to Decimal Conversion = Disable

Code 5 Hex to Decimal Conversion = Enable

DEFAULT

$CC5CT00

$CC5CT01

$CC5HD00

$CC5HD01
