GS1 DataBar (RSS)

Product Reference Guide

273

GS1 DataBar (RSS)

NOTE

GS1 DataBar variants must be enabled to read the bar codes below

(see "

GS1 DataBar (RSS)" on page 273

GS1 DataBar-14

10293847560192837465019283746029478450366523

(GS1 DataBar Expanded Stacked)

1234890hjio9900mnb

(GS1 DataBar Expanded)

08672345650916

(GS1 DataBar Limited)

55432198673467

(GS1 DataBar Omnidirectional Truncated)

90876523412674

(GS1 DataBar Omnidirectional Stacked)

78123465709811

(GS1 DataBar Omnidirectional Stacked)
