Enter/Exit Programming Mode Stop Bits
22 Heron™ HD3130
Baud Rate (continued)
Stop Bits
The stop bit(s) at the end of each transmitted character marks the end of trans-
mission of one character and prepares the receiving device for the next charac-
ter in the serial data stream. The number of stop bits selected (one or two)
depends on
the number the receiving terminal is programmed to accommo-
date. Set the number of stop bits to ma
tch host device requirements.
DEFAULT
$CR2BA04
Baud Rate = 19,200
$CR2BA05
Baud Rate = 38,400
$CR2BA06
Baud Rate = 57,600
$CR2BA07
Baud Rate = 115,200
$CR2ST00
1 Stop Bit
$CR2ST01
2 Stop Bits
To Next Page
