Chapter 2
Setup
Unpacking
Check carefully to ensure the scanner and any cables or accessories ordered are
present and undamaged. If any damage occurred during shipment, contact
Technical Support on page 3.
KEEP THE PACKAGING. Should the unit ever require service, it should be
retu
rned in its original shipping container.
Setting Up the Scanner
Follow the steps provided in this section to connect and get your scanner up
and communicating with its host:
1. Connect the Interface Cable at the sc
anner as shown in Figure 2. To dis-
connect the cable, insert a paper clip or similar object into the opening
shown (item #3).
2. Connect the other end to the Host (see the next section,
Connect Host Inter-
face on page 6
and Figure 3).
3. Modify "
Customizing Configuration Settings" on page 14
(only if modifications
are needed from factory settings).
Figure 2. Cable Connection/Disconnection at the Scanner
Cable Connector
Paper clip
r
To Next Page
