Symbologies Enter/Exit Programming Mode

Product Reference Guide

113

Code 39

The following options apply to the Code 39 symbology.

Code 39 Enable/Disable

When disabled, the scanner will not read Code 39 bar codes.

Code 39 = Disable

Code 39 = Enable

DEFAULT

$CC3EN00

$CC3EN01

Default Chapter3
