Enter/Exit Programming Mode Codabar

162 Heron™ HD3130

Codabar Interdigit Ratio

This feature specifies the maximum ratio between an intercharacter space and

module for Codabar labels.

Codabar Interdigit Ratio = Disable

Codabar Interdigit Ratio = 1

Codabar Interdigit Ratio = 2

Codabar Interdigit Ratio = 3

DEFAULT

Codabar Interdigit Ratio = 4

Codabar Interdigit Ratio = 5

$CCBIR00

$CCBIR01

$CCBIR02

$CCBIR03

$CCBIR04

$CCBIR05

Default Chapter3
