Symbologies Enter/Exit Programming Mode

Product Reference Guide

187

ISBT 128 Force Concatenation

When enabled, this feature forces all ISBT 128 labels to be concatenated.

NOTE

DEFAULT

ISBT 128 Force Concatenation = Disable

ISBT 128 Force Concatenation = Enable

This option is only valid when

ISBT 128 Concatenation on

page 185

is enabled. (see page 10-185).

ISBT 128 Advanced Concatenation Options

NOTE

Use the Datalogic Aladdin configuration application or Contact Customer Support to

set up pairs of label types for concatenation.

$CI8FC00

$CI8FC01
