Datalogic Heron HD3100 User Manual

Technical Specifications
252 Heron™ HD3130
Programming Mode
The following indications ONLY occur when the scanner is in Programming Mode.
INDICATION DESCRIPTION LED SPEAKER
Label Program-
ming Mode
Entry
A valid programming label has
been scanned.
LED blinks continuously
Scanner sounds four low fre-
quency beeps.
Label Program-
ming Mode
R
eje
ction of
Label
A label has been rejected. N/A
Scanner sounds three times at
lowest
frequency & current
volume.
Label Program-
ming Mode
Acceptance of
Pa
rtia
l Label
In cases where multiple labels
must be scanned to progr
am
one feature, this indication
acknowledges each portion as
it is successfully scanned.
N/A
Scanner sounds one short
beep at highest frequency &
curren
t volume.
Label Program-
ming Mode
Acceptance of
Program
m
ing
Configuration option(s) have
been success
fully pro-
grammed via labels and the
scanner has exited Program-
ming Mode.
N/A
Scanner sounds one high fre-
quency beep and 4 low fre-
quency beeps followed by
re
se
t beeps.
Label Program-
ming Mode Can-
cel Item Entry
Cancel label has been scanned. N/A
Scanner sounds two times at
low frequency and current vol-
ume.
Troubleshooting
Problem Possible Cause Possible Solutions
Nothing happens when the scan
button is pulled.
No power to the imager.
Check system power. Ensure power
su
pply is connected.
Interface or power cables are
lo
ose
.
Ensure all cable connections are secure.
LED comes on, but bar code does not
decode.
Imag
er not programmed for cor-
rect bar code type.
Ensure imager is programmed to read
t
h
e type of bar code scanned. Refer to
the PRG for more information.
Bar code label is unreadable.
Check the label to ensure it is not
defaced. Try
scanning
another bar code
type.
Distance between imager and bar
cod
e
is incorrect.
Move imager closer to or further from
the bar code.
Bar code is decoded but not trans-
mitted to the host.
Imager not programmed for the
correct host
type.
Scan the appropriate host type bar code.
Refer to the PRG for more information.

Datalogic Heron HD3100 Specifications

General

Brand	Datalogic
Model	Heron HD3100
Category	Barcode Reader
Language	English
