Enter/Exit Programming Mode Code 4

206 Heron™ HD3130

Code 4

The following options apply to the Code 4 symbology.

Code 4 Enable/Disable

Enables/Disables ability of scanner to decode Code 4 labels.

DEFAULT

Code 4 = Disable

Code 4 = Enable

Code 4 Check Character Transmission

This feature enables/disables transmission of an optional Code 4 check charac-

ter.

Code 4 Check Character Transmission = Don’t Send

Code 4 Check Character Transmission = Send

DEFAULT

$CCREN00

$CCREN01

$CCRCT00

$CCRCT01
